Hi bought this quad with a few leaks and other issues which thanks to excellent advice from these forums I thought I’d sorted them till I washed it down and found oil underneath.
It is coming from the seal around the gear changer pedal as it looks like someone has banged the housing flat on one side. Knowing how easily aluminium is broken I don’t wanna risk tapping it back into shape. Would a new seal fit or would the distortion of the housing render it useless.
thanks in advance
Can anyone point me to a good set of instructions for changing front diff oil on a 1987 Suzuki LT4WD? I can almost guess which bolts are drain & fill... but I've been wrong before... 😆
I found some partial posts on other forums and they linked out to dead images and whatnot. Any help appreciated.
This thing is running pretty good, got the front brakes back to life, electric start works fine, seat cover fixed up, plastics stitched back together...
BEFORE (last week):
By Ed Zeppeli
I have some wobble in my right rear wheel. Too much wobble.
So I've torn into it and will need two bearings and two (different) seals. I'd like to get them locally if possible but need to know the number on the sides of the bearings and seals as I don't know that my bearing shop can source them by vehicle model. I'm told they're very common bearings.
Any idea what the numbers are if mine end up being illegible?
Fixing up a 1998 King Quad 300. The rear brake was locked up, and the owner tried to force it free and snapped the axle.
I disconnected the brake cable, and tapped on the backing plate with a soft mallet to get the brake freed up. When I pulled off the brake drum a bunch of nasty rust water came out.
Once I had the axle out, I popped the boot off so I could see the inner u joint so I could phase/synchronize it with the outer. There was a flat steel disc floating around in the boot, looks like it used to be pressed into the end of the axle. Glad I got that out of there before it munched up the joint.
The book says the yokes should be aligned, I couldn't get mine aligned. They were always 7 degrees off from each other. A bit frustrating, maybe that's within the tolerance limits?
But I got it all back together and it runs great.
Just bought a used 2014 outlaw 90.
I noticed at the top of the front shocks there is 2 mounting holes for the shocks. By the markings the shocks used to be mounted in the inner holes now the shocks are mounted using the outer holes. Googling I can't find the reason for these two holes.
2nd question is about the rear suspension
When I push the suspension down it is very slow at raising back up. Should it be slow? Is it a safety thing for kids so it doesn't bounce them off. The spring adjustment is on the second lob from softest. Has painted arrows so I'm guessing it's from factory.
Has anyone touched one of these machines and could tell me if this is normal?
