tssetmr

1999 Yamaha Wolverine - Pinion Torque Specs

Recommended Posts

I'm in need of the torque specs for the rear output shaft pinion nut torque specs. Does anybody have them? As it is a pain in the @#$% to do I only want to do it this one time.

Thank you.

Share this post


Link to post
Share on other sites


That's wonderful. Thank you so much! Great resource. I did this job several years ago but because I got in a hurry and didn't remove the ujoint I was unable to properly torque the nut. Therefore it had worked its way off. I now used Loctite red and properly torqued it. Thanks for your help!

Share this post


Link to post
Share on other sites
