I like to ride in wooded and grassy areas. It takes my mind off the everyday routines and helps me deal with my father's cancer. Also gives me a reason to get involved with forums like this one.
I have a gentleman that asked me to service his bayou for him. I have always wondered what oil should be used in atv engines? Pros? Cons? What weight should be used in what type of weather? Is there one kind that I could bulk buy and safely used in any quad I worked on or owned? What about performance? Engine Life? This has always been a 🤔🤔🤔 area for me with quads as far as why you would use one type of oil over another....
After looking at the wire diagram I saw the blue w/black stripe wire is coming from the neutral and reverse lights looking for ground thru the neutral and reverse switches. If it finds ground, the lights come on. The same wire also comes from the neutral relay looking for ground at the same neutral and reverse switches. So it was easy to trick the relay into thinking the engine is in neutral all the time without having the light on all the time. Just cut the blue w/black wire at the relay and ground it. Easy
Sorry the pics aren't better
Now it starts in any gear and indicator lights work as they should.
I was reading another forum recently about fuel leaks and possibility of fire happening. Reminded me of an incident I had a few years ago while working at a Can Am dealership. The quad was a stolen & recovered Outlander 650 that had been tampered with. These quads have an electronic safety system, similar to their DESS system on the sleds. You cannot bypass the key switch and get spark without a computer with factory software. Anyway, I was trying to determine what was damaged since the thief had attempted to hot wire various electronic parts. I got all the extra wires removed and things looked back to stock. Pulled the spark plugs and was going to check for ignition and if the starter still worked. Well, they both worked alright and guess what - the cylinder was flooded with fuel! Instant flames with gas spraying all over...great!! I managed to use my hands to put out the fire, good thing I had on gloves (but choked they were ruined of course, haha). Seems it's possible to flood an engine with efi when you put power straight to the injectors, doh! As in much of life, you cannot take things for granted (I'd only seen carbs flood like that). And even though it had spark, the quad still needed a new ECM to run - that part alone was $1200. So lets hear your stories, crazy stuff happens every day I'm sure.
By Dra O
posted a while back - it was running at one point - I have all the plastic shroud off - it's down to frame and engine now
-fuel pump: when line from petcock is attached, no fuel comes out other side to carb; the line to the carb is open (can blow through it); I thought when I cranked engine that the pump would spit out fuel on other side but it does not; I removed fuel pump and opened it up - diaphragm looks good - but internal areas had lotsa calcification build up - I cleaned this out and dried it good - the clear plastic pieces (?diaphragms) aren't broken - the spring w/ steel ball on end moves freely; am putting it back on tomorrow; but can anyone answer about the pump? isn't it supposed to pump fuel through it... to other side... to carb? puzzling
-along with fuel pump: I replaced petcock 3 weeks ago (gas tank had rusty fuel in bottom - cleaned it out prior to new petcock); when I turn petcock arrow NOT to on or reserve, fuel comes out of line; when I turn it to on or reserve, fuel doesn't come out; puzzling
-I don't know what's on back of fuel pump - it's a valve that has a hose coming out of it - looks like it goes to engine/carb - I haven't traced this out yet - what is it?
-can squirt gas on air filter and engine will run for 2-3 seconds then stop - fuel in top of carb (under diaphragm) does same
-it likely needs carb rebuild - will get to this - but something isn't allowing fuel to get from fuel pump to carb
-I THINK it has a mikuni model x carb - diaphragm is ID 26mm OD 68mm - hard to find inexpensive diaphragm, I guess because it's a model x
-last thing - I replaced solenoid due to old one clicking; I HAVE to be charging the battery or it won't start/turn over - battery just goes dead; but if charging, it'll turn over nicely; i'm guessing it's a bad battery
-any help appreciated - I've never owned an ATV before - inherited this beast from grandparent in-law
Similar Tagged Content
By Julio Cano
The tires which I bought on ebay cannot be balanced, it’s out of round.Tried riding and had wobble.
It was mounted in shop and they also put it on a rim they had sitting in the shop and same issue to confirm it.
Are they defective ?
They have brand new high quality tires for my old suzuki gsxr750 and want about $600 for two tires.
Is it worth it to pay that much or buy another set of front rear tires like Hexautoparts which has good reviews on trustpilot.com?
Any recommendations ?
By marek porowski
It’s kind of ATV related question as I need new trailer tires to tow my 4 wheeler.
Does anybody have any experience with loadstar 12” trailer tires ?
There is not to many choices for trailer tires here in Ontario and I was wandering if somebody can recommend me something.
By Shawn Hurt
I have a 2013 KQ I bought it new but rolled it a few years ago. I have replaced the left lower A-arm and left tie rod, the steering is still a little sketchy as I just eye balled the alignment. But the major issue is the left front tire cambers out at the top and has wore the tire bald. Tires have about 2000 miles on them but other 3 are half tread and left front is a slick.. I can not see anything else bent and don't know what to do..
