By HSTAR
Hey I have a 1997 big bear 350 4x4
I replaced the shifter shaft and the shift arm linkage and the rod when I installed them all I was unaware that you had to line the dot on the shifter shaft with the gap on the linkage arm gap put it all back together and rode it I can't get it to shift in the right gears I can move the shift cam by hand and goes in different gears but with the shifter shaft in it riding I can't put it in R or N
Anyone know how to line up the shifter shaft and the shift cam s
-
By N00bie
From Arkansas. Just bought a 2012 Gator 850i RSX because I could not pass up the price. BUT it has an idle problem. So, to be honest, I joined just to get a service manual. I have a choice: 1)Buy a hard copy: ~$100; 2)Buy a CD ~$35.00; Get a direct download for free posting 10 times; or get a download for $29.00 (subscription). Haven't decided what to do yet.
-
By Louznmemind
Howdy y'all, I'm trying to fix a neighbors 2015 Brute Force 300. Came in with hard to start and won't idle except on choke issue. I pulled the carb and found the pilot jet as well as the emulsion tube partially clogged. Cleaned up everything, put it back together, still having issues... It will start right up on choke and will also start off choke if you give it just a touch of throttle but it absolutely will not idle unless it's choked just a touch. Also, excuse my ignorance but I'm assuming the "dial" thingy attached to the carb that turns in and out is for setting idle??
-
By DarkRider
This is something I'm extremely curious about. Has anyone ever attempted to buy a quad (or any other vehicle) from an impound lot? I've always wondered if this could be a bargain, or a waste of time. Google searches do turn up some helpful results. Looks like the state of NJ holds auctions online which I'd be a bit hesitant about.
My online searches haven't really turned up any results of anyone buying an ATV this way. I'd be really curious if anyone tried this, or knows someone who has. I've actually found a couple pages with online auctions for my state, but none had ATVs.
-
By dhallftworth
Hi everyone, I received a 98 Yamaha Timberwolf from my brother for free, and I'm working on getting it going.
I am having the following problem:
The engine is backfiring through the carb.
I have done the following to try and get the four wheeler running:
Rebuilt the carb and set the air screw to 1-1/4 turn out and the circlip at middle position 3
Replaced the coil, because the cable was loose at the coil end
Repaired the main ground, coming from the battery
Replaced the ignition switch, because my brother couldn't find the key. New switch tested good
Tested the kill switch and it tested good
New coil tested goodfor both primary and secondary coils
Pickup coil resistance is at 195, which is correct
My source coil, is where I believe the issue is. The resistance is 310ohms, and it should be between 428-523ohms
When I opened the stator housing, there was significant oil, which I have read is normal. Does it sound like I'm on the right track replacing the source coil? Could this be causing my backfiring issue? It looks like the source coil is part of the stator assembly, is this correct? 4BD-85510-20-00 STATOR ASSY
-
