    • By Chris2018
      Does anyone have the cdi box wiring? I'm trying to hook up aftermarket cdinbox and i keep confusing myself with the trigger signal wire trigger ground wire and 12v. Any help would be appreciated thank you for your input
    • By Tom Pavlak
      Hi Everyone - Need some help.
      Got a nice little 220...clean machine. wiring is a mess. I have a diagram however, the one I have has 4 wires coming from the ignition switch not 2 like mine. So, I cant trace wires properly.
      There is a white one that runs to the Solenoid, and a brown wire...from the Ignition...I dont know where its supposed to go. Also, on the Solenoid, there are 3 wires..W to ignition, B to start relay and B/Y runs up to the front of the machine...and is not plugged into anything...and there isnt a "Mate" missing it. How do they plug into the 4 open shovels by the 20A fuse?
      I'm pretty sure my Lights and start switch/Lights are correct.
      Problem I cant get anything...new battery...cant get the start button to work, cant get any power to the lights or switches...so I know something is not grounded or..
      Any advice would be greatly appreciated.
      Tom
    • By colt
      Here is what I have collected over the years and maybe it will help someone else.
      There are so many and several are too large to upload as attachments, so see any thing you need just shoot me a PM and your email and I will get them on the way to you as fast as I can.
      Thanks
      50cc to150cc Service Manual For Tank Motorsports.pdf
      linhai-atv-service-manuals-linhai-300-parts-manual.pdf
      1986 CH250 ELITE SERVICE MANUAL.pdf
      Charging and ignition systems for atvs.pdf
      Chinese ATV Frame Diagram.jpg
      Chinese ATV Repair Shop Manual - Clutch Diagram - Exploded Views.jpg
      Chinese ATV Repair Shop Manual - Cylinder Head Diagrams.jpg
      Chinese ATV Repair Shop Manual - Torque Specifications.jpg
      Chinese ATV Repair Shop Manual - Valve Clearances.jpg
      Dinli-501-PARTS-DINONP.pdf
      Dinli-601-Parts2003BEAST-DIAMONDBACKNP.pdf
      Dinli-DL-5015erviceManual.pdf
      Dinli-DL-502PartsManual.pdf
      Dinli-DL-5025erviceManual.pdf
      Dinli-DL-503PartsManual.pdf
      Dinli-DL-601,DL-603ServiceManual.pdf
      Dinli-DL-603PartsManual.pdf
      Dinli-DL-604PartsManual.pdf
      Dinli-DL-701PartsManual.pdf
      Dinli-ServiceManual-150ccATV.pdf
      DTE150-2-150cc.pdf
      Eagle ATV Fender Body Parts Exploded Diagram.jpg
      Eagle ATV Rear Axle - Exploded Diagram.jpg
      GY6_Top_End_Rebuild.pdf
      Leopard-parts.pdf
      Linhai_260servicemanual.pdf
      Odes-400-Repair.pdf
      Piston Ring Installation 4 Stroke Engines.jpg
      Roketa-ATV-10(ATV-DO43)-Repair.pdf
      Roketa-ATV-11(ATV-D037)-Repair.pdf
      SLA-120-PARTS.pdf
      SLGK-110-PARTS.pdf
      SLGK-150R-PARTSMANUAL.pdf
      SLGK-400R-PARTS.pdf
      SLU-500-600-700-PARTS.pdf
      slu700db-700UTV-Service-Manual.pdf
      tao-tao-atv-parts-cylinder-rebuild-kit-for 90cc-100cc-110cc-engines-p-13331.pdf
      Trouble Shooter Guide for BATTERY DRAINED Chinese Engines.txt
      Trouble Shooter Guide for NO-COMPRESSION.txt
      Trouble Shooting No Crank.txt
      Troubleshooting.pdf
      YX125CC BREAKDOWN.pdf
      _________________________________________________________________________________





      50 to 150cc GY6 Shop Manual.pdf
      Arrow 150 Engine Service Manual.pdf
      Eton Shop Manual YXT-150.pdf
      GY6 Shop Manual.pdf
      Yerf Dog Spiderbox GX150 Service Manual.pdf
    • By Jteam
      Hello from NC ladies and gents. Been lurking here off and on and don't think I have ever posted up.

      I have a 2009 Honda Rubicon. I was having a shifting problem with the Hondamatic. Determined it to be a loose connection on the gray 21 pin connector at the control unit (ECM/PCM). I located a source for the connector and replaced it. This improved the connectors feel greatly, HOWEVER, even though I thought I was careful transferring the wires/pins from the old connector to the new connector, I must have crossed up a couple wires because now the gear position display (switch is new) no longer works. It worked fine before the connector change.

      No matter where I have looked, I cannot find a "pin out" for the ECM connectors. The factory service manual does not show it and I have a connection at a dealer and their service techs don't have the pin out either! I was a Chrysler/Plymouth/ Dodge tech in another life and cant imagine th factory not providing pin out diagrams for diagnostics!

      I am at a loss unless I either replace the harness, OR find someone that can take multiple photos of the wires going into the gray connector so I can compare mine.

      Any help or advice would be appreciated. I will also post up the location I found the connectors if that is allowed, since it seems that they fail with some age.

      connector source:
      Motorcycle Connectors
      We have Vintage and modern Sport-bike Motorcycle Wiring Harness electrical Connectors, These connectors are purchase directly from the manufacturer, And in many cases the OEM Supplier, The terminals and connectors are superior quality. Most are Manufactured in the, Japan, USA or Europe. Bullet... www.cycleterminal.com
