I have a 2004 Kawasaki KLF300. I’m not sure What is the black/yellow, brown, and red wire wrapped together in the wire hornets of a klf300. I got it used and notice some wires not connected. They are located in the front area
The reason why I am asking because I’m having issues with it firing up. I cleaned the carb put new spark plugs and gas.
Hi everyone....I have 2006 750 Kawasaki Brute Force, my belt light came on, checked the belt, all's well there, I done this once before a long time ago, so long ago I can't remember how or what has to be done to get the light off. Yes I do have a tech manual, spent a lot of time looking for my answer to getting the light out, no luck. Too anyone that can help with this it would be much appreciated....Thanks
Hi all, new to this forum so thanks in advance for the help.
I have recently brought a 2013 power steering fuel injected foreman 500.
It has a crack in the front casing and was running rough. I have since replaced the front engine casing and this has made no difference to the engine performance.
It starts and idles but bogs down and starts to die once throttle is applied.
It maybe be but it also sounds very load.
I have uploaded a video link of it.
I’m working on a Kawasaki Bayou KLF400 for a family member that doesn’t have spark. I’ve already replace the ignition switch and the stator which were defective. The stator had a melted connector and one of the phase had low resistance and low VAC output.
What I’ve figured out so far is that I’m not getting 12V to the ignition coil when I turn the key to the ON position. From what I understand, the 12V should come from the CDI. I’ve resistance tested both wires going from the CDI to the ignition coil (Green/white and black/yellow). They are fine. The only 12V coming from the ECU is on the yellow/red wire.
I don’t have the wiring diagram for the 400 but I’m working with the one for the Bayou 300 which looks pretty similar except for the wire color between the CDI and ignition coil. On the 300 diagram, the yellow/red wire goes to the ignition coil, not the black/yellow… All the other wires color match except for this one. Not sure if that’s normal?
