I have a gentleman that asked me to service his bayou for him. I have always wondered what oil should be used in atv engines? Pros? Cons? What weight should be used in what type of weather? Is there one kind that I could bulk buy and safely used in any quad I worked on or owned? What about performance? Engine Life? This has always been a 🤔🤔🤔 area for me with quads as far as why you would use one type of oil over another....
After looking at the wire diagram I saw the blue w/black stripe wire is coming from the neutral and reverse lights looking for ground thru the neutral and reverse switches. If it finds ground, the lights come on. The same wire also comes from the neutral relay looking for ground at the same neutral and reverse switches. So it was easy to trick the relay into thinking the engine is in neutral all the time without having the light on all the time. Just cut the blue w/black wire at the relay and ground it. Easy
Sorry the pics aren't better
Now it starts in any gear and indicator lights work as they should.
I was reading another forum recently about fuel leaks and possibility of fire happening. Reminded me of an incident I had a few years ago while working at a Can Am dealership. The quad was a stolen & recovered Outlander 650 that had been tampered with. These quads have an electronic safety system, similar to their DESS system on the sleds. You cannot bypass the key switch and get spark without a computer with factory software. Anyway, I was trying to determine what was damaged since the thief had attempted to hot wire various electronic parts. I got all the extra wires removed and things looked back to stock. Pulled the spark plugs and was going to check for ignition and if the starter still worked. Well, they both worked alright and guess what - the cylinder was flooded with fuel! Instant flames with gas spraying all over...great!! I managed to use my hands to put out the fire, good thing I had on gloves (but choked they were ruined of course, haha). Seems it's possible to flood an engine with efi when you put power straight to the injectors, doh! As in much of life, you cannot take things for granted (I'd only seen carbs flood like that). And even though it had spark, the quad still needed a new ECM to run - that part alone was $1200. So lets hear your stories, crazy stuff happens every day I'm sure.
By Dra O
posted a while back - it was running at one point - I have all the plastic shroud off - it's down to frame and engine now
-fuel pump: when line from petcock is attached, no fuel comes out other side to carb; the line to the carb is open (can blow through it); I thought when I cranked engine that the pump would spit out fuel on other side but it does not; I removed fuel pump and opened it up - diaphragm looks good - but internal areas had lotsa calcification build up - I cleaned this out and dried it good - the clear plastic pieces (?diaphragms) aren't broken - the spring w/ steel ball on end moves freely; am putting it back on tomorrow; but can anyone answer about the pump? isn't it supposed to pump fuel through it... to other side... to carb? puzzling
-along with fuel pump: I replaced petcock 3 weeks ago (gas tank had rusty fuel in bottom - cleaned it out prior to new petcock); when I turn petcock arrow NOT to on or reserve, fuel comes out of line; when I turn it to on or reserve, fuel doesn't come out; puzzling
-I don't know what's on back of fuel pump - it's a valve that has a hose coming out of it - looks like it goes to engine/carb - I haven't traced this out yet - what is it?
-can squirt gas on air filter and engine will run for 2-3 seconds then stop - fuel in top of carb (under diaphragm) does same
-it likely needs carb rebuild - will get to this - but something isn't allowing fuel to get from fuel pump to carb
-I THINK it has a mikuni model x carb - diaphragm is ID 26mm OD 68mm - hard to find inexpensive diaphragm, I guess because it's a model x
-last thing - I replaced solenoid due to old one clicking; I HAVE to be charging the battery or it won't start/turn over - battery just goes dead; but if charging, it'll turn over nicely; i'm guessing it's a bad battery
-any help appreciated - I've never owned an ATV before - inherited this beast from grandparent in-law
Similar Tagged Content
STREET LEGAL - ONE OF A KIND HARLEY DAVIDSON 4-WHEELER $9,500 OBO Sporster 883 bored to 1200cc built into a Street Legal Licensed and Insured 4-Wheeler. It has 400ex front end, 250r Rear end. All chromed out with new black gloss paint. I have a $500 Dakota Digital Speedometer to go with it (needs installed). I also have an extra rear gear and extra set of off-road mud tires and rims. Brakes need to be adjusted, and there's a few other touch ups that will place it into show quality. I haven't started it in a while. Ran Great last run. This bike has over $20k invested in work and time. It will go about 120 mph or more. With the other gear it will go about 60 mph. It rides great on and off road. It brings trophies and turns heads at shows. Shoot me a message or offer if interested. (May entertain trades). I will entertain any offers. This is your only chance to own a Street Legal 4 wheeler. Currently titles and registered in KY.
By Dana Hudson
Hey everyone, hoping to get some help here... my kids 03 KTF 50 Quad has always ran great... they were riding it a couple of hours a few days ago and it died a couple of times (not normal) but started right back up. A few days later my 5 year old wanted to take it for a spin so I started it (2 pulls) and he took off.. he made it a couple hundred yards and it died and we havnt been able to start it since. I have new gas, good spark and 120 psi compression.. it will not start with starter fluid in the intake or even in the cylinder.. the fuel bowl has fuel at the carb... what am I missing? It’s driving me crazy!!
So i was riding the other day and my quad randomly shut off. It started back up and ran completely fine for a little while and then it started idling terribly.
I cleaned the carb and changed all the jets and everything except the float due to the rebuild kit not coming with one and it actually runs worse then it did before.
It will run and idle decent now but when I give it gas it dies.
Does anybody know what could be wrong?
I also changed the spark plug and air filter along with the oil and oil filter.
i have a 2000 suzuki king quad lt-f300f that i picked up as a project bike. it didnt run well when it was parked outside 5 years ago. it cranked after putting fresh gas - but would not run below half throttle, i took apart the carb, cleaned debris, and re-assembled. i suspect that the pilot needle is sheared off - it never protrudes into the throttle body through the pinhole. now to get the bike to ALMOST idle, the throttle idle adjustment knob is all the way up/in. the pilot needle is turned almost all the way in/up (if i understand correct, it should nominally be out 2 1/4 turns or so). and like i said, it will ALMOST idle. floods easily, rides rough.
wanted to hear from those more experienced than me with suzukis - and im self-taught atv repair, so dont laugh too hard if my verbiage/part names is way off.
facing the driver's side of the bike [US] there are three hoses on this side of the carb. without a service manual or way of knowing what was messed up before i got it, i think i have them right: front hose as a vacuum to the petcock, middle hose as vacuum to the fuel pump, rear hose as fuel line from the fuel pump. running the bike in prime position results in flooding even while riding. with all hoses disconnected from the carb, fuel slowly drips from the vacuum line connected to the petcock.
so just my speculation is that the diaphragm in the petcock is split, and the pilot needle is broke off - causing my inability to not quite idle and the rough ride. this suzuki is hoses and cables everywhere compared to the honda ranchers and yamaha warriors i am used to. I would like to have a plan rather than: replace everything at once.
is my speculation on the right track, or could something else be at play? say, if the compression was non-existent, would that cause non-idling? i am all ears, look forward to the input.
