Ok so I'm back lol
I got two arctic cat 300s that I am either trying to make one of the two or if possible I'll get them both running. I have a good start but I am struggling to find a wiring diagram that actually shows the connections.
Both bikes were tore apart and some wiring was spliced and all screwed up so I have been tracing wires and redoing the connections.
On one bike I have a neutral light and it will let the use e start to turn starter motor, thing is on that bike the motor is stuck engaged so when I pull the pull cord it's turning the starter motor as well.
On the other bike it is free and works as it should but I can't get the neutral indicator light to come on. Or any for that matter. I have been going through the fuses which all have power as well as the e start switch.
I'm wondering if anyone has come across some similar issues, I am checking the neutral switch tonight, I have been checking the wiring and comparing it to the bike that is working (in that sense) but both bikes are missing some things
I'm wondering if it is a better option to pull the good motor out and rebuild it then put it into the bike with the indicator lights working. But on that bike all the bushings and linkages are toast so there's a lot of work to either bike. I'd like to at least get the engine to fire up before I invest too much energy into swapping motors.
So if anyone has some info or can send me in the direction of a good wiring diagram it would be much appreciated. Thanks
