Similar Forum Topics
-
By Does_This_Look_Bent?
Hey everyone, I just replaced the carp on my 98 Kodiak 400 with PN#4SH-14101-00-00. It starts and idles perfect, but once it’s good and warmed up, it bogs out at 3/4 throttle or more… it sounds like it’s bouncing off a rev limiter haha… I tried the air fuel screw, all the way in and out 2-1/2, and it made it a touch better… tried 2 turns and no different. Am I missing something?
-
By Kaz
Troubleshooting a no spark issue, was running OK, maybe a little rich, turned it off, now no spark. I've checked/ohmed out the main key switch, the start/stop switch, neutral switch, brake switch - all good. It will crank the starter, but no spark with the starter or when I try the pull start. I've checked all fuses and diodes. Swapped battery. New plug. New coil. Swapped in a used CDI - no help. Traced, removed, cleaned, reattached all grounds. Removed things like my winch from the circuits to be sure a bad relay or something was dragging it down. When testing voltages, the orange wire going from the CDI to the ignition coil shows no/very low voltage-shouldn't it have 12V on it? Sometimes I get a very weak, intermittent glow on my spark tester, but not enough to fire the plug. I've checked continuity on just about all wires in the harness. Checked/cleaned/lubed w dielectric grease- all connections, redid a few that looked old/dirty. I've checked the stator resistances, all good, but have a stator and rectifier ordered anyway, will arrive Sunday. I verified that the rectifier has a voltage output back to charge the battery while cranking - 10.5-11V, low, but expected while starter is engaged. What else can I check as part of troubleshooting? I have a Haines service manual, but the 1999 350 4x4 seems to be an odd model, there isn't an exact electrical diagram for it, but found one for another year that has all the same number of wires and same color wires, so I've referenced that. Any hints, tips or advice would be appreciated! Thanks!
-
By geezer99
I have an Axis 500 made by Hisun. I uses a solid rear gearbox with no differential action.
I would like to convert this to a true differential with locking ability. I've searched all over trying to find a source with no luck.
Has anyone done this before, or know of a source?
Thanks, Tom
-
By ruslan1o1
Hey everyone looking for a suggestion of where i can start looking. But first I'd like to explain what happened. Took the bike this morning got it started in 6 degrees celsius in 6-7 kicks? No choke. Drove 6km and when shifted to next gear bike decided to just shut off, stopped checked everything out seemed good, started first kick and on i went, drove maybe another 2km bike did same thing but this time it took me 10-15 kicks to get it started, on the third time after a kilometer decided not to start at all. Kicked it like a 450 a couple hundred times, nothing. So far checked gas is good, bypassed fuel filter and on/off valve to eliminate that problem, hot wired the kill switch in case something got corroded there. Nothing. Any suggestions would be welcomed. (Heard valve adjustment are a must do?)
-
By Joeguy
I been working on this thing for like 2 months now and it will not run right, is very smokey, and has a pretty loud tap that i think is in the bottom end. Not sure how much the parts are but i will put the time into it if they are pretty cheap. Im not very experienced but going off how the plug looks and the oil on top of the piston i am getting a whole lot of oil coming in from somewhere, not sure if it can come from the valves or if the rings are just shot, my cheap scope cant really see the walls of the cylinder too well.
20241009_123850.mp4
-
