I had a quad fall in my lap a couple weeks ago. The only things I knew about it was it was a Kawasaki Bayou 220, was in pretty rough shape and was free. I couldn't say no to a fun little project. I've been looking a different ATV forums gathering quite a bit of info and decided this was the one I wanted to join.
Thanks to this forum, I found the VIN under about an inch of mud and cross referenced it to be a '98. It had been sitting outside for at least 5 years and was told it ran when parked, but had no brakes. Squirrels or mice had been chewing on the handlebar controls and it's generally just kind of beat up.
So far, I've gone through the carb (not near as bad as I expected), freed up the brakes (will probably need new cables), replaced the spark plug, air filter, petcock and put a new battery in it.
The gas tank had been empty and looked clean so I put some fresh gas in it and tried to crank it today. I got a neutral light, but the starter button did nothing. I tried pull-starting it and it wouldn't fire. I checked the plug and wasn't getting a spark. I started digging and found some potential issues and some definite problems.
I have a wiring diagram I found on here but it's just a picture or scan out of a book and hard to read. I don't see a reference to a black/yellow wire, which is my first problem.
First, it that a factory crimp? One of those wired looks like it goes to the connector in the 2nd pic. Is that just a spade lug type connector? I pulled on it with some needle nose pliers but it didn't seem to want to come off. In the 3rd pic, should there be a fourth wire?
I've read through and bookmarked the threads Andrew Baker and Arizona have going but I figured I needed to start with these obvious issues first. I have lots of pictures, so if there is something else you want to see, just ask. If I don't already have a pic, I'll take one.
By Tom Pavlak
Hi Everyone - Need some help.
Got a nice little 220...clean machine. wiring is a mess. I have a diagram however, the one I have has 4 wires coming from the ignition switch not 2 like mine. So, I cant trace wires properly.
There is a white one that runs to the Solenoid, and a brown wire...from the Ignition...I dont know where its supposed to go. Also, on the Solenoid, there are 3 wires..W to ignition, B to start relay and B/Y runs up to the front of the machine...and is not plugged into anything...and there isnt a "Mate" missing it. How do they plug into the 4 open shovels by the 20A fuse?
I'm pretty sure my Lights and start switch/Lights are correct.
Problem I cant get anything...new battery...cant get the start button to work, cant get any power to the lights or switches...so I know something is not grounded or..
Any advice would be greatly appreciated.
By Dra O
posted a while back - it was running at one point - I have all the plastic shroud off - it's down to frame and engine now
-fuel pump: when line from petcock is attached, no fuel comes out other side to carb; the line to the carb is open (can blow through it); I thought when I cranked engine that the pump would spit out fuel on other side but it does not; I removed fuel pump and opened it up - diaphragm looks good - but internal areas had lotsa calcification build up - I cleaned this out and dried it good - the clear plastic pieces (?diaphragms) aren't broken - the spring w/ steel ball on end moves freely; am putting it back on tomorrow; but can anyone answer about the pump? isn't it supposed to pump fuel through it... to other side... to carb? puzzling
-along with fuel pump: I replaced petcock 3 weeks ago (gas tank had rusty fuel in bottom - cleaned it out prior to new petcock); when I turn petcock arrow NOT to on or reserve, fuel comes out of line; when I turn it to on or reserve, fuel doesn't come out; puzzling
-I don't know what's on back of fuel pump - it's a valve that has a hose coming out of it - looks like it goes to engine/carb - I haven't traced this out yet - what is it?
-can squirt gas on air filter and engine will run for 2-3 seconds then stop - fuel in top of carb (under diaphragm) does same
-it likely needs carb rebuild - will get to this - but something isn't allowing fuel to get from fuel pump to carb
-I THINK it has a mikuni model x carb - diaphragm is ID 26mm OD 68mm - hard to find inexpensive diaphragm, I guess because it's a model x
-last thing - I replaced solenoid due to old one clicking; I HAVE to be charging the battery or it won't start/turn over - battery just goes dead; but if charging, it'll turn over nicely; i'm guessing it's a bad battery
-any help appreciated - I've never owned an ATV before - inherited this beast from grandparent in-law
By Steven Urban
First time using this forum. Owned a Kawasaki dirt bike once, had no issues. But I picked up this 4 wheeler at an auction. They stated it ran, but only needed a battery. Well I do not believe that was all true.
Some pictures are attached. Not sure why, but the whole air filter stuff was removed. They had some small thing inserted as a make shift air filter.
I purchased a battery to try this all out. Waiting to return it and get the proper size, as it was too big for the battery box. But here is my issue I had while the battery was connected.
1 - The lights on the steering column did not come on. Not sure if they work or not.
2 - The starter solenoid seems to be bad. I have a new one on order.
3 - In the pick, there is another rusted part. Not sure what that part is or what it is used for.
4 - What is the 12v rectifier? square bodied part.
So when I hooked the battery up. Pushing the start button did nothing. Pulling the cord to try and pull start, it turned, but would never fire. I have put in a new spark plug as well, it looked worn out. With electric start, I crossed over the posts on the start solenoid, it turned over, but would never fire and start.
I have read a few other threads and it stated something about needed the neutral light on. SOmething about a kill switch.
Any help would be appreciated.
