By
Brantley11
Hey everybody,
My proficiency is with Hondas and Yamahas make me see RED!
This bike is my brother in law's, it has 1199 miles on it and went from running great to dead with no start. Every once and a while it will start and sputter for 2 seconds. It is extremely sporadic when it fires but never runs for longer than 3 seconds.
Here is where we sit:
Brand New Fully Charged battery
Carb was cleaned with air hose and carb cleaner then into the ultrasonic cleaner with Aircraft aluminum cleaner
New Shindy Carb kit (made in Japan version)
Cleaned out petcock and gas tank
New 93 Non Ethanol Gas
New Spark Plug
It gets a spark through the spark test light every time
Bluish white spark
When holding the spark plug 1/4" - 3/8" away from head it will jump and spark to the head
Good Compression
Here are the readings:
Pickup Coil 519 Ohms (range 459-561)
Charging Coil 266 Ohms (range 270-330)
Lighting Coil 0.700 (range 0.702-0.858)
Spark plug Cap 10.58 Ohms (10kohms
Ignition Coil Primary Coil 0.5 ohms (range 0.18-0.28 ohms)
Ignition Coil Secondary Coil 8.20 kOhms (range 6.32-9.48 kOhms)
Would y'all think stator and pick up coil, rectifier or CDI are the culprit?
