New member here,
I have searched here and other places and have not found an answer to my problem. As the title says I have a 2014 420 Rancher that recently started having an issue were the revs before the clutch engages.
I have checked the oil level (per the service manual) and replace the Valvoline ATV 10w40(less than 5 hours) with 10W30 GN4 for good measure. I have used the "pin" method to pull a DTC. I shows a 8-1 which is a TPS error. This makes some sense, as if the computer doesn't read throttle position correctly, it could have this symptom. I have checked the source voltage, and tested the TPS off the quad with a Fluke and a power supply at 5v. It is smooth and does not seem to be a bad sensor. I am confused by the DTC, because the PS light blinks the code, not the check engine light. However, there are no PS codes of that value. This condition appeared after a couple days of driving in the cold (~32°) and driving though some water/bogs.
A couple questions. First has anyone seen this issue, and do you have any suggestions? I have followed the troubleshoot right up to the point of replacing the ECU, which I don't seem to have one on the shelf :)
Second, anyone used a OBDII reader with an a 4pin adapter to pull codes? If so, what system do you use?
Beyond the rev issue, the quad runs and starts perfectly and when it decides, the clutch grabs tight (no slipping)
By Fhai Catz-eteh
I have been on K&N's website, but cannot seem to find a cross reference for my 2009 Outlander 400 XT EFI air filter. The OEM BRP filter number is 707800264. They (K&N) lists many that look like the original that I am replacing, but it would be awesome if someone has a K&N model number they have installed that has the right fit and function. Any info would be greatly appreciated -Cheers!
I'm fitting a new carb on my King Quad LTF300. From China. Only one I could find in UK. I think it should have 2 vacuum ports.
The vacuum port for the petcock is silver coloured. I can feel the pulsing vacuum. Putting the tube to the petcock there operates the petcock100% perfectly.
I can't identify the vacuum port for the fuel pump. The new carb is identical to the old EXCEPT that in what I think is the 2nd old fuel vacuum position is a brass upright port with a very small hole. When running, there is no vacuum I can feel and putting the fuel pump vacuum line there does not give a decent fuel flow - only a small trickle.
Is this the fuel pump vacuum port - see photo?
The carb came with a silver coloured screw-ended 1.5 inch long loose port in the box. See photo. Is it intended that you unscrew the brass port somehow and put in the silver one?
I'd really appreciate your help At the moment I can only do 10mph in a stuttering fashion on the level!
and put in the silver one?
these are what i have in my collection ... always looking for more
1999 - 2004 Can-Am All Line service manual
2003 Can-Am Rally 200 service manual
2006 Can-Am Bombardier Outlander Series 400 & 800 Shop Manual
2006 Can-Am 400 & 800 Outlander service manual
2006 Can-Am 400 ATV Motor Shop Manual
2006 Can-Am 800 ATV Motor Shop Manual
2007 - 2008 Can-Am Renegade 500 & 800 / Outlander 500-650-800 service manual
2008 Can-Am DS450 Shop Manual
