Similar Forum Topics
-
By DaleJAM
so i cant read the vin clearly but i have added some pictures, hopefully someone sees it correctly. took a picture of what it looks like, they painted it Green It is underside a SKY BLUE original. has one spark plug . 3 relays in the back + rectifier. has one relay in the front. has cdi in the front three plugs off it.
If you need more info or pictures please ask.
the wire harness is trashed i want to rewire it but correctly.
-
By Kaz
Troubleshooting a no spark issue, was running OK, maybe a little rich, turned it off, now no spark. I've checked/ohmed out the main key switch, the start/stop switch, neutral switch, brake switch - all good. It will crank the starter, but no spark with the starter or when I try the pull start. I've checked all fuses and diodes. Swapped battery. New plug. New coil. Swapped in a used CDI - no help. Traced, removed, cleaned, reattached all grounds. Removed things like my winch from the circuits to be sure a bad relay or something was dragging it down. When testing voltages, the orange wire going from the CDI to the ignition coil shows no/very low voltage-shouldn't it have 12V on it? Sometimes I get a very weak, intermittent glow on my spark tester, but not enough to fire the plug. I've checked continuity on just about all wires in the harness. Checked/cleaned/lubed w dielectric grease- all connections, redid a few that looked old/dirty. I've checked the stator resistances, all good, but have a stator and rectifier ordered anyway, will arrive Sunday. I verified that the rectifier has a voltage output back to charge the battery while cranking - 10.5-11V, low, but expected while starter is engaged. What else can I check as part of troubleshooting? I have a Haines service manual, but the 1999 350 4x4 seems to be an odd model, there isn't an exact electrical diagram for it, but found one for another year that has all the same number of wires and same color wires, so I've referenced that. Any hints, tips or advice would be appreciated! Thanks!
-
By Joeguy
I been working on this thing for like 2 months now and it will not run right, is very smokey, and has a pretty loud tap that i think is in the bottom end. Not sure how much the parts are but i will put the time into it if they are pretty cheap. Im not very experienced but going off how the plug looks and the oil on top of the piston i am getting a whole lot of oil coming in from somewhere, not sure if it can come from the valves or if the rings are just shot, my cheap scope cant really see the walls of the cylinder too well.
20241009_123850.mp4 -
By BuckBilly
Good morning to all !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Let's see if we can make this a daily event.
-
By USRaider
Hello all!
I was given a 2000 Suzuki Quadrunner 500 (Quad 500 Runner?) and its current state is a bit of a mystery!
Kept indoors but hasn't been run in 5 years. We're not trying the engine until the gas is replaced, and the tires are reinflated. But the previous owner said their only issue was stalling when shifting to reverse without giving some throttle.
I'm optimistic! See y'all around!
-
