  1. ATVmechanic

    ATVmechanic

  2. You may not be getting enough fuel. It may be time to remove that carb and give it a good cleaning. How is your choke working, is it fully operational? If you adjust you idle control screw, does it run better?
  3. Exactly...you can run a low restriction high performance muffler..running with no muffler for a prolonged amount of time is not good.
  4. Diesels.....nice machine, but I prefer the gas model.
  5. If you are looking for "sympathy", it's in the dictionary between "shit" and "syphilis".
  6. Congrats on the new quad. Yeah, I believe you will need to get it set by the delaer most likely to have the fan turn on sooner and stay on longer.
  7. I would not put champs in a Honda...use: Spark plug Standard: DPR8Z (NGK), X24GPR-U (DENSO) For extended high speed riding: DPR9Z (NGK), X27GPR-U (DENSO)
  8. Here are the specs: Carburetor BSR36 I.D. Mark 5YT1 00 Main jet #142.5 Main Air Jet #35 Needle-clip Position 5JFC39-2 Needle Jet P-0M Pilot Air Jet #65 #165 Pilot Outlet 1 Pilot Jet #22.5 Pilot Screw (Turns Out) 2.25 Bypass 1 0.8 Bypass 2 0.8 Bypass 3 0.8 Throttle Valve Size #105 Starter Jet #70 Fuel Level 4 - 5 mm (0.16 - 0.20 in) Float Height 13 mm (0.51 in) Engine Idling Speed 1,450 - 1,550 rpm Vacuum Pressure at Idling Speed 33.3 kPa (9.83 inHg)
  9. The horizontal marks should be level with the cylinder head cover mating surface at the same time the "T" mark aligns with the index notch on the case cover. The vertical line on the cam sprocket should point straight up.
  10. Are the back tires locked up?

×
×
