After looking at the wire diagram I saw the blue w/black stripe wire is coming from the neutral and reverse lights looking for ground thru the neutral and reverse switches. If it finds ground, the lights come on. The same wire also comes from the neutral relay looking for ground at the same neutral and reverse switches. So it was easy to trick the relay into thinking the engine is in neutral all the time without having the light on all the time. Just cut the blue w/black wire at the relay and ground it. Easy
Sorry the pics aren't better
Now it starts in any gear and indicator lights work as they should.
Hey there! New guy here! So I bought an 87 250. I turn the key and it has ignition light. I press run and the engine turns over. Guy I bought it from said the carbs may need cleaning, I worked them good cleaned and blown out. I reinstalled the carb and still doing the same thing. It’s getting fuel, the battery is brand new and charged I’m lost here!( purchased a new carb on its way) anyone have any ideas
i have a 91 moto 4 100. has electric start only. for as long as i could remember we have always pushed start it. after riding for while you shut it off. you are able to hit the start button and it will start right up. anyone know where i should start with fixing this issue? im fixing it up for my niece. thank you in advance.
By Steven Urban
First time using this forum. Owned a Kawasaki dirt bike once, had no issues. But I picked up this 4 wheeler at an auction. They stated it ran, but only needed a battery. Well I do not believe that was all true.
Some pictures are attached. Not sure why, but the whole air filter stuff was removed. They had some small thing inserted as a make shift air filter.
I purchased a battery to try this all out. Waiting to return it and get the proper size, as it was too big for the battery box. But here is my issue I had while the battery was connected.
1 - The lights on the steering column did not come on. Not sure if they work or not.
2 - The starter solenoid seems to be bad. I have a new one on order.
3 - In the pick, there is another rusted part. Not sure what that part is or what it is used for.
4 - What is the 12v rectifier? square bodied part.
So when I hooked the battery up. Pushing the start button did nothing. Pulling the cord to try and pull start, it turned, but would never fire. I have put in a new spark plug as well, it looked worn out. With electric start, I crossed over the posts on the start solenoid, it turned over, but would never fire and start.
I have read a few other threads and it stated something about needed the neutral light on. SOmething about a kill switch.
Any help would be appreciated.
